CrossManager

Versions

Extensions

Versions

Extensions

3DXML

1.0

.3dxml

3MF

.3mf

3Shape DCM

.dcm

ACIS

Up to 2019   1.0

.sat .asat .sab   .asab

V5

.sat

CADDS

explicit +   parametric 4x To 5.12

._pd _pd

._pd

CATIA V4 2D

4.15 to 4.24

.model .dlv .dlv3   .exp

CATIA V4 3D

4.15 to 4.24

.model .dlv .dlv3   .exp .session

4

.model

CATIA V5 2D

R10 to V5-6R2020   (R30)

.CATDrawing

CATIA V5 3D

R10 to V5-6R2020   (R30)

.CATPart   .CATProduct

R14 & R19

.CATPart   .CATProduct

CATIA V6 / 3DEXPERIENCE 2D

R2010x to R2021x

.3dxml

CATIA V6 / 3DEXPERIENCE 3D

R2010x to R2021x

.3dxml

CEREC - Sirona Dental

up to 3.8

.sdt .cdt .idt

CGR

R10 to V5-6R2020   (R30)

.cgr

R14 & R19

.cgr

COLLADA

1.4.1

.dae

Creo View

.ol .ed .edz .pvs   .pvz

DWG / DXF 2D

2.5 to 2018

.dwg .dxf

DWG / DXF 3D

2.5 to 2018

.dwg .dxf

DXF

.dxf

EMF

18 to ST8

.emf

FBX

.fbx

7.4

.fbx

glTF

2.0

.gltf .bin .glb

IFC

2x3 & 2x4   & 4 add1

.ifc .ifcxml   .ifczip

IGES

up to 5.3

.igs .iges

5.2

.igs

Inventor

9 to 2021

.ipt .iam

JT

6.4 to 10.5

.jt

8.0 & 9.5

.jt

OBJ

all

.obj

.obj

Open CASCADE

up to 7.5.0

.brep

Parasolid

V7 to V32

.x_t .x_b   .xmt_txt .xmt_bin

V10 to V32

.x_t .x_b

PDF 2D

1.7

.pdf

PDF 3D

1.7

.pdf

PLMXML

4 & 6

.plmxml

PRC

8137

.prc

Procera

.c3s

ProE / Creo Parametric 2D

2000i to Creo 7.0

.drw .drw.*

ProE / Creo Parametric 3D

2000i to Creo 7.0

.prt .prt.* .xpr   .asm .asm.* .xas

Revit

2015 to 2021

.rvt .rfa

Rhino

5(64 bits) to 7

.3dm

Robcad

.rf

.rf

Solid Edge 2D

ST1 to 2021

.dft

Solid Edge 3D

10 to 2021

.par .psm .asm

SOLIDWORKS 2D

2004 to 2021

.slddrw

SOLIDWORKS 3D

2009 to 2021

.sldprt .sldasm

2006

.sldprt .sldasm

STEP

AP203 (E1, E2),   AP214 (up to E3), AP242 (E1, E2)

.stp .step .stpZ

AP203 (E1, E2),   AP214 (E3), AP242 (E1, E2)

.stp .stpZ

STL

.stl

Binary or ASCII

.stl

UG NX 2D

NX to NX 1946

.prt

UG NX 3D

15 to NX 1946

.prt

NX 5

.prt

Unisurf

.uni

VDA

All

.vda

.vda

VRML

2.0

.wrl
